SMART TRI-LED WEATHERPROOF Gen.4 1200 16W 2200LM 840 IP65 ED
PRODUCT FEATURES
Product Features:
- Surface-mounted LED weatherproof luminaire IP65 luminaire. Luminaire housing made of polycarbonate, with opal polycarbonate diffuser, anti-tamper stainless steel clips and locking screws.
- 16W, luminous flux 2200lm, fixture’s efficacy of 138lm/w, CCT: 4000°K CRI>80. ● Ambient temperature -40 to +50 C. Safety class (EN 61140): II,
- Ingress protection IP65 / IK08 5 Joules (DIN EN 60529): impact resistance level in accordance with IEC 62262
- Average life span >50000 hours L70/B50 @ 25°C Ta.
- SMD2835 light source with low-voltage constant current driver, low power consumption efficiency non-dim HPF>0.9 100V-240VAC/220-240VAC, 50-60Hz led driver.
- Dimensions L1205 x W85 x H80 / LF: 810
- 5-Year warranty
PRODUCT OVERVIEW
PRODUCT DATA
PRODUCT ASSET DOWNLOADS
PRODUCT OVERVIEW
PRODUCT OVERVIEW
| Item Code | SLWP120.70149 |
| Product Name | TRI-LED WEATHERPROOF Gen.4 1200 16W 2200LM 840 IP65 ED |
| Technology | LED |
| Power Consumption | 16W |
| LED Source | SMD2835 |
| Dimmable | NON-DIMMABLE |
| Installation Type | SURFACE MOUNTED |
| Luminous Flux | 2200lm |
| Colour | Neutral White |
| Colour Temperature | 4000K |
| Beam Angle | 120° |
| CRI (Ra) | 80 |
| Input Voltage | 100V-240VAC/220-240VAC, 50-60Hz |
| Power Factor | >0.90 |
| IP Rating | IP65 |
| Material | PC+PC |
| Working Environment | ﹣20℃~50℃ |
| Product Size (mm) | L1205 x W85 x H80 / LF: 810 |
Product Overview
Project Application
Product name
Technology
LED
General application
Logistics and Industry
E-number FI
Product name
Fixture luminous flux (lm)
2200
Luminaire efficacy (lm/W)
Colour temperature (K)
4000
Colour Variation Initial (SDCM)
Electrical protection
Warranty
PRODUCT DATA
Product Data
General data
Product name
Technology
LED
Housing
PC Polycarbonate
Mount
Celling surface mounting, Suspended, Wall surface mounted
General application
Logistics and Industry
Operating temperature range (°C)
-20 ... +55
Warranty
